48 Volt Parker Lucifer actuator 495905A4
The Parker’s broad range of IECEx and ATEX electrical parts for the Process Industry includes many product solutions for the different hazardous areas preventing risk of explosion. This range includes product solutions for any scope in the relative industry: from the most resistant 316L solutions for offshore applications to the smallest and most compact Zone 2 options for piped or NAMUR valves. In any case, the most relevant benefit is represented by the coil modularity. Different options may be mounted on the same valve and different valves may be assembled with the same coil design. This unique value delivered by Parker can optimize the total ownership costs delivering high reliability, extreme flexibility and best competitiveness.
Markets:
– Power Generation
– Oil & Gas
– Pharmaceutical
– Food & Beverage production, storage
-Chemical Production
Applications:
– Piped or Namur Valve control
– Valve Actuation
Features/Benefits:
-Coil Modularity
– Wide Range of Protection Mode
Maximum Ambient Temperature: +80°C
ATEX Specifications Met: II 2 G Ex db mb IIC T4 Gb
Minimum Ambient Temperature: -40°C
Electrical Connection: Electric connection is done in the connection box on an easily accessible connector terminals. The introduction of the cable
Power Supply Voltage: 48V 50Hz
Coil Type: ELECTRICAL PARTS 37 mm
Insulation Class: H 180 °C
Coil Power Consumption: 8 W
Coil Temperature Range: -40 to 80 °C
Specifications Met: ATEX/IECEx – CCC – KCs
48 Volt Parker Lucifer ATEX actuator 495905A4: https://ph.parker.com/us/en/product/iecex-atex-electrical-parts-for-fluid-control-solenoid-valves/495905a4
